Hãng sản xuất

GIGABYTE

Form Factor

Micro ATX Form Factor; 24.4cm x 17.4cm

CPU hỗ trợ

Hỗ trợ: CPU Intel® Core™ i7/ i5/ i3/ Pentium®/Celeron®

Socket

1 x LGA 1151

Chipset

Intel B150

Bộ nhớ trong

2 x DDR4 DIMM sockets supporting up to 32 GB RAM DDR4 2133 MHz

Sata



6 x SATA 6Gb/s connectors

RAID

Intel® SATA RAID 0/1/10/5

LAN

Realtek® GbE LAN chip (10/100/1000 Mbit)

USB

6 x USB 2.0/ 3.0 port + 6 x USB 2.0 / 1.1 port

Khe cắm mở rộng

1 x PCI Express x16 slot, running at x16

  PCI Express graphics card , PCIEX16 slot.2 x PCI Express x1 slots

1 x PCI slot

BIOS

2 x 64 Mbit flash

Use of licensed AMI UEFI BIOS

Support for DualBIOS™

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Phụ kiện đi kèm

 Chặn main
